Спецификации

Manufacturer
ASUS
Graphics
1 x DisplayPort**;1 x HDMITM port***;1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output****;* Graphics specifications may vary between CPU types.;** Supports max. 4K@60Hz as specified in DisplayPort 1.4.;*** Supports 4K@60Hz as specified in HDMI 2.1.;**** Supports max. 4K@120Hz as specified in DisplayPort 1.4.;***** VGA resolution support depends on processors' or graphic cards' resolution.;****** While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.
CPU's supported
Supports Intel® Core™ Ultra Processors (Series 2), LGA1851*;Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset
Intel® Z890 Chipset
Expansion Slots
Intel® Core™ Ultra Processors (Series 2);-1 x PCIe 5.0 x16 slot;Intel® Z890 Chipset;-2 x PCIe 4.0 x16 slots (support x4 mode);-1 x PCIe 4.0 x16 slot (supports x1 mode)
Memory type
4 x DIMM slots, max. 192GB, DDR5;Support up to 8666+MT/s (OC),Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*;Dual channel memory architecture DIMM Fit;Supports Intel® Extreme Memory Profile (XMP) memory module;ASUS Enhanced Memory Profile III(AEMPIII);* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration;** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Connectors
Fan and Cooling related;-1 x 4-pin CPU Fan header;-1 x 4-pin CPU OPT Fan header;-1 x 4-pin AIO Pump header;-4 x 4-pin Chassis Fan headers;Power related;-1 x 24-pin Main Power connector;-2 x 8-pin +12V CPU Power connector;Storage related;-4 x M.2 slots (Key M);-4 x SATA 6Gb/s ports;USB;-1 x USB 10Gbps connector (supports USB Type-C®);-2 x USB 5Gbps headers support 4 additional USB 5Gbps ports;-2 x USB 2.0 headers support 4 additional USB 2.0 ports;Miscellaneous;-3 x Addressable Gen2 headers;-1 x Aura RGB header;-1 x Clear CMOS header;-1 x COM Port header;-1 x Front Panel Audio header (F_AUDIO);-1 x S/PDIF Out header;-1 x SPI TPM header (14-1pin);-1 x 10-1 pin Front PanelSystem header;-1 x Thunderbolt™ (USB4®) header
Audio
Realtek 7.1 Surround Sound High Definition Audio CODEC*;- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking;- Supports up to 24-Bit/192 kHz playback Audio Features;- Audio Shielding;- Premium audio capacitors;- Dedicated audio PCB layers;* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
LAN
1 x Realtek 2.5Gb Ethernet; ASUS LANGuard
BIOS
256 (128+128) Mb Flash ROM, UEFI AMI BIOS
Form Factor
ATX Form Factor 12 inch x 9.6inch ( 30.5 cm x 24.4 cm )
OS
Windows 11 (22H2 & later), Windows 10 64-bit (21H2 & later)
Warranty
36 Months
