Спецификации
- ManufacturerAsus
- SocketSocket AM5
- Graphics1 x HDMITM port; 2 x USB4® (40Gbps) ports support USB Type-C® display outputs
- CPU's supportedAMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
- ChipsetAMD X870E
- Expansion SlotsAMD Ryzen™ 9000 & 7000 Series Desktop Processors; 2 x PCIe 5.0 x16 slots with Q-Release Slim (supports x16 or x8/x8** or x8/x4/x4 modes); AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors; 2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16(G5)_1 & total bandwidth for x8, PCIEx16(G5)_2 will be disabled); AMD Ryzen™ 8500 & 8300 Series Desktop Processors; 2 x PCIe 4.0 x16 slots with Q-Release Slim (only supports PCIEx16(G5)_1 & total bandwidth for x4, PCIEx16(G5)_2 will be disabled)
- Memory type4 x DIMM slots, max. 256GB, DDR5; Supports up to; 8200+MT/s(OC) with Ryzen™ 9000 Series Processors,; 9000+MT/s(OC) with Ryzen™ 8000 Series Processors,; 8000+MT/s(OC) with Ryzen™ 7000 Series Processors,; ECC and Non-ECC, Un-buffered DIMM; Dual Channel Memory Architecture; Supports AMD Extended Profiles for Overclocking (EXPO™); ASUS Enhanced Memory Profile (AEMP); NitroPath DRAM Technology;
- ConnectorsFan and Cooling related; 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 2 x 4-pin Chassis Fan headers; 2 x 4-pin Radiator Fan headers; 2 x W_PUMP+ headers; 1 x VRM Heatsink Fan header; Power related; 1 x 24-pin Main Power connector; 2 x 8-pin +12V CPU Power connector; 1 x 8-pin PCIe Power connector; Storage related; 3 x M.2 slots (Key M); 1 x DIMM.2 slot supports 2 x M.2 slots (KeyM); 1 x SlimSAS connector; 4 x SATA 6Gb/s ports; USB; 1 x USB 20Gbps connector (supports USB Type-C®); 1 x USB 10Gbps connector (supports USBType-C®); 2 x USB 5Gbps headers support 4 additional; USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional; USB 2.0 ports; Miscellaneous; 1 x 6-pin ARGB Gen 2 header to support 2 x ARGB Gen 2 headers; 2 x Addressable Gen 2 header; 1 x Alteration PCIe mode switch; 2 x BCLK button; 1 x BIOS Switch; 1 x FlexKey button; 1 x Front Panel Audio header (F_AUDIO); 1 x LN2 Mode jumper; 12 x ProbeIt Measurement Points; 1 x ReTry button; 2 x RSVD switchs; 1 x RSVD header; 1 x Safe Boot button; 1 x Slow Mode switch; 1 x Start button; 1 x 10-1 pin System Panel header; 1 x Thermal Sensor header; 1 x Pause switch
- AudioROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082*; - Impedance sense for front and rear headphone outputs; - Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking; - High quality 120 dB SNR stereo playback output and 110 dB SNR recording input; - Supports up to 32-Bit/384 kHz playback on front panel; Audio Features; - SupremeFX Shielding Technology; - ESS® ES9219 QUAD DAC; - LED-illuminated audio jacks; - Rear optical S/PDIF out port; - Premium audio capacitors; * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.; ** The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
- LAN1 x Realtek 5Gb Ethernet; 1 x Marvell® AQtion 10Gb Ethernet; ASUS LANGuard
- BIOS2 x 256 Mb Flash ROM, UEFI AMI BIOS
- Form FactorE-ATX Form Factor; 30.5 cm x 27.7 cm
- OSWindows® 11
