Спецификации
- ManufacturerASUS
- Graphics1 x HDMI™ port;2 x USB4® (40Gbps) ports support USB Type-C® display outputs
- CPU's supportedAMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
- ChipsetAMD X870E
- Expansion SlotsAMD Ryzen™ 9000 & 7000 Series Desktop Processors;1 x PCIe 5.0 x16 slot (supports x16 mode);AMD Ryzen™ 8000 Series Desktop Processors;1 x PCIe 4.0 x16 slot (supports x8/x4 mode);AMD X870E Chipset;1 x PCIe 4.0 x16 slot (supports x4 mode)
- Memory type4 x DIMM slots, max. 256GB, DDR5;Supports up to;8000+MT/s(OC) with Ryzen™ 9000 Series Processors,;8400+MT/s(OC) with Ryzen™ 8000 Series Processors,;8000+MT/s(OC) with Ryzen™ 7000 Series Processors,;ECC and Non-ECC Un-buffered DIMM*;Dual Channel Memory Architecture ;Supports AMD EXTended Profiles for Overclocking (EXPO™);NitroPath DRAM Technology;ASUS Enhanced Memory Profile (AEMP)
- ConnectorsFan and Cooling related ;1 x 4-pin CPU Fan header;1 x 4-pin CPU OPT Fan header;1 x 4-pin AIO Pump header;5 x 4-pin Chassis Fan headers;Power related ;1 x 24-pin Main Power connector;2 x 8-pin +12V CPU Power connectors;Storage related ;5 x M.2 slots (Key M) ;4 x SATA 6Gb/s ports;USB 1 x USB 20Gbps connector (supports USB Type-C®);2 x USB 5Gbps headers support additional 4 USB 5Gbps ports;3 x USB 2.0 headers support additional 6 USB 2.0 ports ;Miscellaneous;3 x Addressable Gen 2 headers;1 x CPU Over Voltage jumper;1 x FlexKey button ;1 x Front Panel Audio header (F_AUDIO);1 x Start button;1 x 10-1 pin System Panel header;1 x Thermal Sensor header
- AudioROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080*;- Impedance sense for front and rear headphone outputs;- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking;- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input;- Supports up to 32-Bit/384 kHz playback;Audio Features ;- Audio Shielding- Savitech SV3H712 AMP;- Gold-plated audio jacks;- Rear optical S/PDIF out port ;- Premium audio capacitors;- Audio cover;* The LINE OUT port on the rear panel does not support spatial audio. If you wish to use spatial audio, make sure to connect your audio output device to the audio jack on the front panel of your chassis or use a USB interface audio device.
- LAN1 x Realtek 5Gb Ethernet;ASUS LANGuard
- BIOS256 Mb Flash ROM, UEFI AMI BIOS
- Form FactorATX Form Factor;30.5 cm x 24.4 cm
- OSWindows® 11 64-bit
- Warranty36 Months
