Спецификации
- Graphics1 x DisplayPort**; 1 x HDMI™port***
- ChipsetIntel® B760 Chipset
- Expansion SlotsIntel® CoreTM Processors (14th & 13th & 12th Gen)*; 1 x PCIe 5.0 x16 slot; Intel® B760 Chipset; 1 x PCIe 4.0 x4 slot; 1 x PCIe 3.0 x1 slot
- Memory type4 x DIMM slots, Max. 192GB, DDR5 7800+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*; Dual Channel Memory Architecture; Supports Intel® Extreme Memory Profile (XMP); OptiMem II
- Connectors1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin AIO Pump header; 3 x 4-pin Chassis Fan headers; 1 x 24-pin Main Power connector; 2 x 8-pin +12V Power connectors; 3 x M.2 slots (Key M) ; 4 x SATA 6Gb/s ports; 1 x USB 10Gbps connector (supports USB Type-C® ); 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports; 3 x USB 2.0 headers support 5 additional USB 2.0 ports; 3 x Addressable Gen 2 headers; 1 x Clear CMOS header; 1 x Front Panel Audio header (AAFP) ; 1 x 20-3 pin System Panel header with Chassis intrude function; 1 x Thunderbolt™ (USB4®) header
- AudioRealtek 7.1 Surround Sound High Definition Audio CODEC; - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback; Audio Features; - Audio Shielding; - Rear optical S/PDIF out port; - Premium audio capacitors; - Dedicated audio PCB layers
- LAN1 x Realtek 2.5Gb Ethernet; TUF LANGuard
- BIOS128 Mb Flash ROM, UEFI AMI BIOS
- Form FactormATX Form Factor; 9.6inch x 9.6 inch ( 24.4 cm x 24.4 cm )
- OSWindows® 11, Windows® 10 64-bit
- Warranty36 Months
