Спецификации
- Graphics1 x DisplayPort**;1 x HDMI™ port***;2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort and Thunderbolt™ video outputs****;* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.;** Supports max. 4K@60Hz as specified in DisplayPort 1.4.;*** Supports 4K@60Hz as specified in HDMI 2.1.;**** In ThunderboltTM 4 mode, supports up to 8K@60Hz x1 with DSC or 4K@60Hz x 2, maximum total bandwidth up to 23.8Gbps or 16Gbps/16Gbps, for resolution support please check DisplayPort 2.1 specs.;***** In DP alt mode, Only one USB Type-C® port supports up to UHBR20 at a time.;****** VGA resolution support depends on processors` or graphic cards` resolution.;******* While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.
- ChipsetIntel® Z890 Chipset
- Expansion SlotsIntel® Core™ Ultra Processors(Series 2)*;-1 x PCIe 5.0 x16 slot;Intel® Z890 Chipset;-1 x PCIe 4.0 x16 slot (supports x4 mode);-1 x PCIe 4.0 x4 slot;-2 x PCIe 4.0 x1 slots
- Memory type4 x DIMM slots, max. 192GB, DDR5;Support up to 9066+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*;Dual channel memory architecture;DIMM Fit;Supports Intel® Extreme Memory Profile (XMP) memory module;ASUS Enhanced Memory Profile III(AEMPIII);* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration;** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
- ConnectorsFan and Cooling Related;-1 x 4-pin CPU Fan header;-1 x 4-pin CPU OPT Fan header;-1 x 4-pin AIO Pump header;-4 x 4-pin Chassis Fan headers;Power Related;-1 x 24-pin Main Power connector;-2 x 8-pin +12V CPU Power connectors;Storage Related;-4 x M.2 slots (Key M);-4 x SATA 6Gb/s ports;USB;-1 x USB 20Gbps connector (supports USB Type-C® );-1 x USB 5Gbps header supports 2 additional USB 5Gbps ports;-2 x USB 2.0 headers support 4 additional USB 2.0 ports;Miscellaneous;-3 x Addressable Gen 2 headers;-1 x Clear CMOS header;-1 x Chassis Intrusion header;-1 x COM Port header;-1 x Front Panel Audio header (F_AUDIO);-1 x 10-1 pin Front System Panel header;-1 x Thermal Sensor header;-1 x Thunderbolt™ (USB4®) header
- AudioRealtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*;- Impedance sense for front and rear headphone outputs;- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers;- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking;- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in);- Supports up to 32-Bit/192 kHz playback*;Audio Features;- Audio Shielding;- Rear optical S/PDIF out port;- Premium audio capacitors;- Dedicated audio PCB layers;- Audio cover;- Unique de-pop circuit;* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
- LAN1 x Intel® 2.5Gb Ethernet TUF LANGuard
- BIOS256 Mb Flash ROM, UEFI AMI BIOS
- Form FactorATX Form Factor 30.5 cm x 24.4 cm
- OSWindows 11 (22H2 & later)
- Warranty36 Months
