Спецификации
- ManufacturerASRock
- ModelX870E Taichi Lite
- SocketAM5
- GraphicsIntegrated AMD RDNA™ graphics (Actual support may vary by CPU); - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz; - 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz*; * Only the CPU's embedded graphics can be displayed through USB4 ports.; If you want to display to a Type-C monitor, please use AM5 Ryzen™ 9000, 8000 and 7000 processors with embedded graphics.
- CPU's supportedSupports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors; Supports ASRock Hyper BCLK Engine
- ChipsetAMD X870E
- Expansion SlotsCPU:; - 2 x PCIe 5.0 x16 Slots (PCIE1 and PCIE2), support x16 or x8/x8 modes*; Chipset:; - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module; - Supports AMD CrossFire™
- Memory typeDual Channel DDR5 Memory Technology; 4 x DDR5 DIMM Slots; Supports DDR5 ECC/non-ECC, un-buffered memory up to 8200+(OC)*; Max. capacity of system memory: 256GB; Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules*; *Please refer to Memory Support List on ASRock's website for more information.
- Connectors3 x Thermistor Cable Headers; 1 x Power LED and Speaker Header; 1 x RGB LED Header*; 3 x Addressable LED Headers**; 2 x CPU Fan Connector (4-pin) (Smart Fan Speed Control)***; 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)***; 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)***; 1 x Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***; 1 x 24 pin ATX Power Connector (Hi-Density Power Connector); 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector); 1 x Front Panel Audio Connector (15μ Gold Audio Connector); 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports); 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s); 1 x Dr. Debug with LED; 1 x Power Button with LED; 1 x Reset Button with LED
- Audio5.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec); WIMA Audio Capacitors (For Rear Outputs); ESS SABRE9219 DAC for Rear Panel Audio (130dB SNR); Individual PCB Layers for R/L Audio Channel; Direct Drive Technology on Front headphone port (Supports up to 600 Ohm headsets); Nahimic Audio
- LAN5 Gigabit LAN 10/100/1000/2500/5000 Mb/s; Realtek RTL8126
- BIOS256Mb AMI UEFI Legal BIOS with GUI support
- Form FactorEATX Form Factor: 12.0-in x 10.5-in, 30.5 cm x 26.7 cm; 8 Layer PCB; 2oz Copper PCB;
- OSMicrosoft Windows® 10 64-bit / 11 64-bit
