Спецификации

Manufacturer
MSI
Model
PRO A520M-S
Socket
AM4
Graphics
1x HDMI™; Support HDMITM 1.4, maximum resolution of 4K 30Hz
CPU's supported
Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series and 3000 G-Series desktop processors
Chipset
AMD A520
Expansion Slots
1x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset); PCI_E2 Gen PCIe 3.0 supports up to x16 (From CPU)
Memory type
2x DDR4, Maximum Memory Capacity 64GB; Memory Support DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE; Ryzen™ 5000 Series Processors max. overclocking:; • 1DPC 1R Max speed up to 4600+ MT/s; • 1DPC 2R Max speed up to 3866+ MT/s; Supports JEDEC Speed; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Memory Overclocking by A-XMP OC mode
Connectors
1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 1x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 4x USB 2.0 ports; 2x USB 5Gbps Type A ports
Audio
Realtek® ALC897 Codec; 7.1-Channel High Definition Audio
LAN
Realtek® RTL8111H 1Gbps LAN
Form Factor
mATX, 200mmx236mm
OS
Support for Windows® 11 64-bit
